Key Information

Range 295 miles

Real World Estimate 251 miles

Battery Size 77 kWh

Co2 0.00 g/km

Rapid Charging Plug CCS

AC Plug Type Type 2

0 - 62mph 7.30 seconds

No. of Seats 5

Charging your Electric Vehicle

Charging at home

Charging time
Range added
Your charge cost
Cost per mile

Get a home installation estimate in 2 minutes

Charging on the road

GRIDSERVE Electric Highway

Latest EV charging technology
Contactless payment facilities
24/7 customer service backup
Powered by sustainable energy

See our charging locations

Full Specification

This data is pulled directly from the CAP-HPI database - Ref# 100405

Standard Equipment

Technical Data

Home Charger

Driver Convenience

12.3" Full TFT drivers supervision instrument cluster
12.3" touchscreen satellite navigation and media centre
Blind spot collision avoidance assist
Bluelink Connected Car Services
Bluetooth connectivity with voice recognition
BVM - Blind spot view monitor
Digital clock
Drive modes select (Eco, normal and sport)
Driver attention warning
eCall emergency system
Forward Collision Avoidance Assist (FCA) - Car, Pedestrian and Cycle
HDA - Highway Drive Assist Level 1.5
Head up display - augmented reality (AR) and standard displays
Hyundai road side assistance
Intelligent speed limit assist (ISLA)
Lane follow assist
Lane keep assist (LKA) - Line and road edge
On board diagnostics
Outside temperature display
Parking - rear view monitor with parking guidance dynamic
Parking distance warning - forward and reverse
Parking system with surround view monitor
PAS
Phone connection with apple carPlay and android auto
Rear cross traffic collision avoidance assist (RCCA)
RTTI - Real time traffic information
Smart cruise control with stop and go functionality
Smart electric tailgate with hand's free opening function
Traffic sign recognition
Wireless phone charging pad

Engine/Drivetrain/Suspension

10.5 kWh 3 Phase On Board Charger
Battery heating system with pre conditioning
Charging cable - 7 pin type 2
Emergency 3 pin connector charging cable (ICCB)
Shift by wire - E shift

Entertainment

Bose Premium Audio system with 7 premium speakers + subwoofer
DAB radio

Exterior Features

Acoustic windscreen
Aero blade wiper
Anthracite side sills
Anti-corrosion treatment
Auto headlights
Automatic windscreen wipers with rain sensor
Body coloured door handles
Chrome bodyside mouldings
Door scuff - Deluxe plate
Dual LED low and high projection headlamps
Electric adjustable/heated/folding door mirrors
Electric front/rear windows with drivers one touch/anti-trap
Frunk - under the bonnet storage
Headlamp surround
Heated and privacy rear windscreen
High gloss black door mirrors
Indicator light on door mirrors
Laminated glazing front and rear windows
LED daytime running lights
LED positioning lights
LED rear combination lights
LED rear fog lights
Privacy rear window
Rear side wing doors
Rear spoiler with integrated LED brake light
Rear wiper
Shark fin roof aerial
Smart high beam headlights
Solar glass windscreen and front windows
Tailgate up lift opening
V2L (Vehicle to Load inside and Outside)
Vehicle to load adaptor
Windscreen auto defog function

Interior Features

12V power outlet in front console
1x USB connectivity port in front
2 x USB ports for row 1
3 rear seat adjustable head restraints
3 rear seats
4 way electrically adjustable drivers seat
60/40 split folding rear seat
A/B/C Pillar trim - Cloth
Alloy pedals
Ambient light in 64 colours
Black glossy beltline
CCS Combo rapid charge port (50kW)
Driver's electric lumbar adjustment
Driver/passenger front seatback pockets
Driver/passenger sunvisors + illuminated vanity mirrors (drivers with ticket holder)
Dual zone climate control air conditioning
Front cup holders
Front head restraints with vertical and horizontal adjustment
Front passenger's seat electric adjustments
Front passenger's seat electric lumbar support
Heated front seats
Heated outer rear seats
Heated steering wheel
Height/reach adjustable steering column
Interior mood lighting
ISOFIX child seat anchorage points attached on outer rear seats
Leather seats
Leather wrapped steering wheel
Luggage compartment light
Luggage cover
Luggage hooks
Manual sliding rear seats
Metal paint effect interior door handles
Rear grab handle with coat hook
Roof trim - Cloth
Second row outer head restraints vertical adjustment
Single front passenger seat
Sliding centre console box
Steering wheel audio controls
Ventilated front seats

Packs

Tech pack - Ioniq 5
Trailer wiring package - Ioniq5

Passive Safety

3 point rear seatbelts
ABS
Childproof rear door locks
Electric parking brake with auto hold function
Electronic stability control
FCA-JT - Forward Collision Avoidance Assist - Junction ( Turning)
Front and outer rear seatbelt reminder and pretensioners
Front center side airbag
Front passenger airbag deactivation switch
Front thorax and pelvis + curtain airbags
Height adjustable front seatbelts
Hill start assist control (HAC)
Impact sensing auto door unlocking
Regenerative brake shift paddles
Smart regenerative braking
Tyre pressure monitoring system with individual tyre pressure warning

Security

Drive away door locking
Immobiliser
Rear occupant alert
Remote control central locking
Smart Key - Keyless entry with Power On/Off button
Thatcham category 1 alarm

Service/Warranty

Warranty - 5 years / unlimited mileage

Wheels

20" Alloy wheels
Tyre repair kit

Electric Vehicle Data

Battery Capacity % guaranteed under warranty

70
Battery Capacity in kWh

77
Battery Charging Scenario 1 - Charge Time (Mins)

369
Battery Charging Scenario 1 - Percentage Change

10-100
Battery Charging Scenario 1 - Power Supply - kW

10.5
Battery Charging Scenario 2 - Charge Time (Mins)

57
Battery Charging Scenario 2 - Percentage Change

10-80
Battery Charging Scenario 2 - Power Supply - kW

50
Battery Charging Scenario 3 - Charge Time (Mins)

18
Battery Charging Scenario 3 - Percentage Change

10-80
Battery Charging Scenario 3 - Power Supply - kW

350
Battery Charging Scenario 4 - Charge Time (Mins)

Not Available
Battery Charging Scenario 4 - Percentage Change

Not Available
Battery Charging Scenario 4 - Power Supply - kW

Not Available
Battery Leased

No
Battery Type

Lithium-ion
Charging Port Location

Left Side Rear
Coupler/Connector Type

Type 2
Maximum Charging Rate - kW

50
Standard manufacturers Battery warranty - Mileage

100000
Standard manufacturers Battery warranty - Years

8
Usable Battery Capacity

Not Available
WLTP - EC (kWh/100km) - Comb

18
WLTP - EC (miles/kWh) - Comb

3.5
WLTP - Pure Electric Range (km) - Comb

476
WLTP - Pure Electric Range (miles) - Comb

295

Emissions - ICE

CO

Not Available
CO2 (g/km)

0
HC

Not Available
HC+NOx

Not Available
Noise Level dB(A)

Not Available
NOx

Not Available
Particles

Not Available
Standard Euro Emissions

Not Available

Engine and Drive Train

Camshaft

Not Available
Catalytic Convertor

Not Available
CC

1
Compression Ratio

Not Available
Cylinder Layout

Not Available
Cylinders

Not Available
Cylinders - Bore (mm)

Not Available
Cylinders - Stroke (mm)

Not Available
Engine Code

Not Available
Fuel Delivery

Not Available
Gears

1 SPEED
Number of Valves

Not Available
Transmission

AUTO

Fuel Consumption - ICE

EC Combined (mpg)

Not Available
EC Directive 1999/100/EC Applies

Not Available
EC Extra Urban (mpg)

Not Available
EC Urban (mpg)

Not Available

General

Alternative Fuel Qualifying

Yes
Badge Engine CC
Badge Power

228
Based On ID

Not Available
Coin Description

Not Available
Coin Series

Ultimate[Tech]
Generation Mark

1
Insurance Group 1 - 50 Effective January 07

35E
Manufacturers Corrosion Perforation Guarantee - Years

12
NCAP Adult Occupant Protection %

88
NCAP Child Occupant Protection %

86
NCAP Overall Rating - Effective February 09

5
NCAP Pedestrian Protection %

63
NCAP Safety Assist %

88
Did at least one aspect of this vehicle's safety give cause for concern?

No
Service Interval Frequency - Months

24
Service Interval Mileage

20000
Special Edition

No
Special Order

No
Standard manufacturers warranty - Mileage

Unlimited
Standard manufacturers warranty - Years

5
Timing Belt Interval Frequency - Months

Not Available
Timing Belt Interval Mileage

Not Available
Vehicle Homologation Class

M1

Performance

0 to 62 mph (secs)

7.3
Engine Power - BHP

228
Engine Power - KW

168
Engine Torque - LBS.FT

258
Engine Torque - MKG

35.7
Engine Torque - NM

350
Top Speed

114

Test Cycles

Emissions Test Cycle

WLTP
RDE Certification Level

N/A

Tyres

Alloys?

Yes
Space Saver?

No
Tyre Size Front

255/45 R20
Tyre Size Rear

255/45 R20
Tyre Size Spare

TYRE REPAIR KIT
Wheel Style

Not Available
Wheel Type

20" ALLOY

Vehicle Dimensions

Height

1605
Length

4635
Wheelbase

3000
Width

1890
Width (including mirrors)

2152

Weight and Capacities

Fuel Tank Capacity (Litres)

Not Available
Gross Vehicle Weight

2450
Luggage Capacity (Seats Down)

1587
Luggage Capacity (Seats Up)

527
Max. Loading Weight

515
Max. Roof Load

80
Max. Towing Weight - Braked

1600
Max. Towing Weight - Unbraked

750
Minimum Kerbweight

1935
No. of Seats

5
Turning Circle - Kerb to Kerb

11.98

Easee One

In Partnership with

The Easee One is our best-seller and for good reason. An unfussy and elegant design combined with its ability to work in tethered or untethered mode - lock the cable in place for ease of access or unplug it for a cleaner look when not in use.

Beautifully compact

The Easee One is one of the best-looking and most versatile EV chargers available today, while also managing to remain impressively small and discreet.

Dimensions - H256 x W193 x D106mm

Universal charging

Thanks to the Easee One's smart design and app, you no longer need to choose between tethered or untethered EV chargers - the Easee does both! Prefer a tethered charger (cable permanently attached)? No problem, simply plug the cable into the Easee One and lock the cable in via the Easee app. If you want the flexibility of an untethered unit (no cable attached), then just remove the cable and plug it in at your own leisure.

This also means the Easee One will work with any EV out of the box.

Easee 7.5m branded cable sold separately (£240). Other branded cables are also available from Smart Home Charge in 5m (£142.00) or 10m (£174.00) from our accessories store.

WiFi and mobile data

Easee One connects to the internet through its in-built WiFi connection. This enables over-the-air updates to add new features and make improvements over time. It also includes a 4G mobile connection for improved internet connectivity and reliability.

Extra colours

The Easee One is available with three colour options as standard: Black, White, and Anthracite Grey

You can purchase other faceplate colours, such as Blue or Red direct from Easee for £35.00 and these are easily swapped.

7kW power output

The Easee One is capable of charging your vehicle at up to 7kW, which will provide around 30 miles of range per hour depending on your vehicle.

Cable security

You can permanently lock your cable into the Easee, removing the fear that someone might remove it.

An Easee branded cable can be bought separately (£240) or you can buy different branded 5m and 10m cables from Smart Home Charge.

Built-in earthing protection

Some charge points require the installation of a copper earth rod, or alternative device, at your property for safety reasons. But this can also add complexity and extra cost to the job. The Easee One avoids the need for this thanks to its built-in PEN fault detection feature.

Future proofed

Easee One can be easily expanded as your EV household grows by "daisy-chaining" up to three chargers. The Easee One will share power evenly between up to three units on the same circuit, so your EVs get their fair share of charge.
