Key Information

Range 80 miles

Real World Estimate 68 miles

Battery Size 37 kWh

Co2 0.00 g/km

AC Plug Type Type 2

0 - 62mph 17.00 seconds

No. of Seats 5

Charging your Electric Vehicle

Charging at home

Charging time
Range added
Your charge cost
Cost per mile

Get a home installation estimate in 2 minutes

Charging on the road

GRIDSERVE Electric Highway

Latest EV charging technology
Contactless payment facilities
24/7 customer service backup
Powered by sustainable energy

See our charging locations

Full Specification

This data is pulled directly from the CAP-HPI database - Ref# 48764

Standard Equipment

Technical Data

Home Charger

Driver Convenience

Acoustic Vehicle Alert System
Bluetooth hands free kit
Cross wind assist
Driver alert system
Electromechanical speed sensitive power steering, height and longitudinally adjustable steering column
Front assist including city emergency braking system
Multi-function display Premium with multi-color display
SD card slot

Entertainment

2 USB interfaces type C in dashboard
4 speakers
Composition colour radio with 6.5" touchscreen
Digital radio reception (DAB+)
Volkswagen app connect

Exterior Features

2nd Row left and right hand side sliding windows
4 stages windshield wiper intermittent control for windshield wipers
Auto dimming interior rear view mirror
Closing rear wing door with unlatching from the inside
Daytime running lights
Electric windows
H7 twin halogen headlamps
Heat insulating windows in cab
Illuminated steps in passenger/load compartment
Left convex exterior mirror
Radiator grille with 2 chrome trims
Rear window with heated insulating glass, heated rear window wiper and washer system
Right convex exterior mirror
Sliding door on the left in load compartment
Tailgate closing with unlatching from the inside

Interior Features

12V socket
Comfort headliner in cab, hardboard roof trim in passenger and load compartment
Dash panel with open stowage compartments, drink holders and lockable glovebox
Dimmable dashboard illumination
Dust/pollen filter
Electronically controlled air conditioning system
Electronically controlled heating system
Folding grab handles on roof frame
Full height side trim panels panels in passenger/load compartment
Heated driver and front passenger seats
Interior plastic loading edge protection
ISOFIX and top tether child seat anchors for the outer seats of the three-seater bench seat
Jack and tool kit
Leather trimmed multi-function steering wheel with height and longitudinal adjustment
LED Interior lighting in load space area
LED Interior lighting with two reading lights in the roof console
Reinforced lashing rings for load restraint system
Rubber floor covering in passenger/load compartment with loading edge protection in rear
Upper dashboard and floor covering in titanium black, lower dashboard in palladium

Safety

Driver and front passenger airbag with front passenger airbag deactivation
Single tone horn
Warning buzzer and light for driver and front passenger seat belt not fastened

Security

Engine immobiliser

Technical

16" chassis with 16" brake system
Automatic post collision braking system
Brake assist
Electronic stability control, ABS, ASR, electronic differnetial lock, hill start assist
Standard anti drum measures
Start/stop system with regenerative breaking

Wheels

16" steel wheels
Low rolling resistance tyres - 205/65 R16 C 107/105T

Electric Vehicle Data

Battery Capacity % guaranteed under warranty

70
Battery Capacity in kWh

37.3
Battery Charging Scenario 1 - Charge Time (Mins)

720
Battery Charging Scenario 1 - Percentage Change

1-100
Battery Charging Scenario 1 - Power Supply - kW

2.3
Battery Charging Scenario 2 - Charge Time (Mins)

330
Battery Charging Scenario 2 - Percentage Change

0-100
Battery Charging Scenario 2 - Power Supply - kW

7.2
Battery Charging Scenario 3 - Charge Time (Mins)

45
Battery Charging Scenario 3 - Percentage Change

0-80
Battery Charging Scenario 3 - Power Supply - kW

50
Battery Charging Scenario 4 - Charge Time (Mins)

Not Available
Battery Charging Scenario 4 - Percentage Change

Not Available
Battery Charging Scenario 4 - Power Supply - kW

Not Available
Battery Leased

No
Battery Type

Lithium-ion
Charging Port Location

Left Side Front
Coupler/Connector Type

Type 2
Maximum Charging Rate - kW

50
Standard manufacturers Battery warranty - Mileage

100000
Standard manufacturers Battery warranty - Years

8
Usable Battery Capacity

32.5
WLTP - EC (kWh/100km) - Comb

28.9
WLTP - EC (miles/kWh) - Comb

2.2
WLTP - Pure Electric Range (km) - Comb

129
WLTP - Pure Electric Range (miles) - Comb

80

Emissions - ICE

CO

Not Available
CO2

0
HC

Not Available
HC+NOx

Not Available
Noise Level dB(A)

Not Available
NOx

Not Available
Particles

Not Available
Standard Euro Emissions

Not Available

Engine and Drive Train

Automatic Transmission

Yes
Bore

Not Available
Catalytic Convertor

Not Available
CC

1
Compression Ratio

Not Available
Cooling System

Not Available
Cylinder Layout

Not Available
Cylinders

Not Available
Engine Codes

Not Available
Engine Layout

Not Available
Engine Make

Not Available
Fuel Delivery

Not Available
Fuel Type

Not Available
Gears

1 SPEED
Manual Transmission

No
Number of Valves

Not Available
Stroke

Not Available
Valve gear

Not Available

Fuel Consumption - ICE

EC

Not Available
EC Combined

Not Available
EC Extra Urban

Not Available
EC Urban

Not Available

General

Alternator Amps

Not Available
Did at least one aspect of this vehicles safety give cause for concern?

No
Badge Engine CC
Badge Power

110
Based On ID

Not Available
Battery AH

Not Available
Battery Volts

Not Available
Chassis Engine Number

Not Available
Clutch

Not Available
Coin Description

Not Available
Coin Gross Vehicle Weight Code

Not Available
Coin Power Output Code

Not Available
Coin Series

Not Available
Coin Wheelbase Description Code

Not Available
Coin Wheelbase Name Code

Not Available
Exhaust System

Not Available
Front Brakes

VENTILATED DISCS
Front Suspension

MCPHERSON STRUTS
Generation Mark

6
Ghost model for valuation purposes

No
Hand Brake

REAR WHEELS
Insurance Group 1

Not Available
Insurance Group 2

Not Available
NCAP Adult Occupant Protection %

Not Available
NCAP Child Occupant Protection %

Not Available
NCAP Overall Rating - Effective February 09

Not Available
NCAP Overall Rating - LCV

Not Available
NCAP Pedestrian Protection %

Not Available
NCAP Safety Assist %

Not Available
Rear Brakes

VENTILATED DISCS
Rear Suspension

COIL SPRINGS
Relative Height

H1
Relative Length

L2
Running Cost League Headings

Not Available
Service Interval Frequency - Months

12
Service Interval Mileage

10000
Special Edition

No
Special Order

No
Standard manufacturers warranty - Mileage

100000
Standard manufacturers warranty - Years

3
Steering

PAS RACK AND PINION
This vehicle is classed as a car for VED purposes

No
Timing Belt Interval Frequency - Months

Not Available
Timing Belt Interval Mileage

Not Available
VAT qualifying vehicle - Seek advice from HMRC

No
Vehicle Homologation Class

N1
Vin/Frame No.

Not Available

Performance

0 to 62 mph (secs)

17.4
BHP

110
Engine Power KW

83
Engine Torque LBS.FT

148
Engine Torque MKG

20.4
Engine Torque NM

200

Test Cycles

Emissions Test Cycle

WLTP
RDE Certification Level

Not Available

Tyres

Alloys?

No
Automatic Clutch

Yes
Plated 3rd Axle

Not Available
Plated 4th Axle

Not Available
Space Saver?

No
Tyre Make

Not Available
Tyre Size Front

205/65 R16
Tyre Size Rear

205/65 R16
Tyre Size Spare

FULL SIZE
Wheel Style

Not Available
Wheel Type

16" STEEL

Vehicle Dimensions

Front Overhang

908
Height

1990
Height (including roof rails)

Not Available
Length

5304
Load Deck Height

Not Available
Load Height

1394
Load Length

1967
Load Space Width Between Wheel Arches

1244
Load Width

1627
Lower Rear Door Width

1290
Rear Door Height

1473
Rear Overhang

993
Side Load Door Height

1264
Side Load Door Width

1017
Turning Circle - Kerb to Kerb

13.2
Wheelbase

3400
Width (excluding mirrors)

1904
Width (including mirrors)

Not Available

Weight and Capacities

Boot Capacity Saloons

Not Available
Fuel Tank Capacity (Litres)

Not Available
Gross Train Weight

3770
Gross Vehicle Weight

3200
Load Space Volume

5
Luggage Capacity (Seats Down)

Not Available
Luggage Capacity (Seats Up)

Not Available
Luggage Capacity - 2nd Row Seats Removed

Not Available
Luggage Capacity - 2nd Row Seats Up

Not Available
Luggage Capacity - 3rd Row Seats Down

Not Available
Luggage Capacity - 3rd Row Seats Removed

Not Available
Luggage Capacity - 3rd Row Seats Up

Not Available
Max. Towing Weight - Braked

1500
Max. Towing Weight - Unbraked

750
Minimum Kerbweight

2225
No. of Seats

5
Payload

975
Plated 2nd Axle

1720
Plated Front Axle

1710
